The AM1600 is a high-power single-channel Class D DSP plate amplifier module specifically designed for active subwoofer applications.
Delivering up to 1600W output, it provides strong low-frequency control, high efficiency, and stable performance under continuous high-load operation.
With an integrated DSP processor, the AM1600 enables precise control of low-pass crossover, EQ, limiter, and protection parameters, making it an ideal solution for powered subwoofer systems in professional audio and OEM manufacturing.
Its compact aluminum plate design with efficient thermal management ensures long-term reliability, even in demanding live sound and installation environments.
1-channel 1600W high-power output, optimized for subwoofer drive
Built-in DSP with adjustable EQ, crossover, limiter, and protection
Class D topology for high efficiency and low heat generation
Integrated SMPS, no external power supply required
Compact plate amplifier design for easy cabinet integration
Stable and reliable operation for continuous low-frequency output
Active / powered subwoofer systems
Professional PA subwoofer cabinets
Touring and rental sound systems
Fixed installation subwoofers
OEM & ODM powered speaker projects
AM1600 | |
8Ω Stereo Power | 1×1600W |
Frequency Response | 20Hz-20KHz ±1dB |
THD+N 1KHz 1W 8Ω | <0.1% |
Signal to Noise Ratio 1KHz | >109dB |
Channel Separation 1KHz | >70dB |
Class | Class: D |
Protection | Short Circuit DCP, OVP, UVP, OCP, OTP |
Operating Voltage | 110V version: 90V-135V / 220V version: 180V-265V |
Input Sensitivity | 1V |
Input Impedance | 20KΩ |
DSP Function | MUTE, Polarity, Gain, Delay, Limiter, EQ, X-Over |
DSP Control | USB and RS-485 |
Dimensions(W×H×D) mm | 477*152*105 |
Net Weight(kg) | 3.6kg |
Gross Weight(kg) | 5.5KG |
