Product Description
The AM825A is a 2-channel Class D plate amplifier module designed for bi-amped full-range speakers and column array systems. Delivering 800W + 250W at 8Ω, this amplifier offers a perfect balance of power, precision, and reliability — making it ideal for compact PA systems or upgrading passive loudspeakers into active configurations.
Each channel of the AM825A is equipped with an independent DSP processor, allowing detailed control over crossover frequency, EQ parameters, delay, limiter, and gain. This flexibility enables professional engineers to fine-tune every aspect of the sound, ensuring smooth integration between low and high frequency drivers.
The amplifier also features USB and RS-485 connectivity, giving users full access to system settings and remote tuning through PC software.
Compact yet powerful, the AM825A integrates all the essential features of a modern active sound system — making it a smart solution for portable PA, installation, or OEM speaker manufacturing.
Key Features
High Power Output
• 800W + 250W @ 8Ω
• Ideal for bi-amped top cabinets or column systems
Built-In DSP Processor
• Mute, Polarity, Gain, Delay, Limiter, Mixer, EQ, Crossover, and APF functions
• Advanced control for precise sound tuning
Smart Connectivity
• Manage via USB or RS-485 interface through PC software
• Easy firmware update and system monitoring
Compact & Efficient Design
• Lightweight Class D architecture with high power density
• Suitable for active loudspeakers and retrofitting passive enclosures
Comprehensive Protection
• Overload, short-circuit, and thermal protection ensure system stability
Applications
Bi-amped line array and column speaker systems
Full-range top cabinets and monitor speakers
Professional active PA systems
Installation projects in venues, clubs, and theaters
OEM loudspeaker manufacturing
Specification
ITEM/MODLE | AM825A |
Output Power | |
8Ω Stereo Power | 800W+250W |
8Ω Stereo Power | 850W+300W |
Frequency Response | 20Hz-20KHz ±1dB |
THD+N 1KHz 1W 8Ω | <0.1% |
Signal to Noise Ratio 1KHz | >100dB |
Channel Separation 1KHz | >80dB |
Class | D |
Protection | Short Circuit, DCP, OVP, UVP, OCP, OTP |
Operating Voltage | 110V version: 90V-135V / 220V version: 180V-265V |
Input Sensitivity | 1V |
Input Impedance | 20KΩ |
DSP Function | MUTE, Polarity, Gain, Delay, |
DSP Control | USB and RS-485 |
Dimensions(W×H×D) mm | 285*136*100mm |
Packing Dimension (mm) | 345*170*160mm |
Net Weight(kg) | 2.5 |
Gross Weight(kg) | 3.5 |
