The DSP5004S is a high-performance 4 output Class D amplifier with integrated DSP, capable of delivering up to 3600 W of dynamic power. Engineered for professional audio applications—including live concerts, houses of worship, multi-zone sound setups, and permanent installations—this amplifier combines efficient Class D amplification with built-in digital signal processing for precise control, low distortion, and robust output, all without requiring external processors. Its compact 1U rackmount construction, effective cooling system, and rugged chassis make it suitable for both touring rigs and fixed installations. Whether powering full-range speakers or managing multiple audio zones, the DSP5004S guarantees reliable operation and crystal-clear sound in demanding environments.
Professional 4-Channel DSP Amplifier delivering up to 3200 W for PA, live performances, and permanent installs.
Built-in DSP Processing with crossover, EQ, delay, and limiter for accurate speaker control and system tuning.
High-Efficiency 4-Channel Output capable of driving subwoofers, full-range loudspeakers, and multi-zone audio configurations.
Compact 1U Rack Design minimizes rack space, shipping complexity, and installation effort.
Advanced Protection Circuits ensure stable operation under continuous high-power conditions.
Live Events & Touring Systems
With powerful output and onboard DSP, the DSP5004S reliably drives line arrays, subwoofers, and stage monitors, offering consistent clarity and punch for concerts, festivals, and touring audio setups.
Professional Installations
Perfect for theaters, auditoriums, and houses of worship, the DSP5004S allows precise DSP tuning to achieve balanced sound coverage across multiple zones.
Multi-Zone AV & Commercial Environments
From conference rooms to clubs and retail spaces, it enables flexible power distribution and tailored audio shaping for multiple speaker zones.
Rental & Production Sound Equipment
Its small 1U form factor, dependable performance, and ease of integration make it an excellent option for rental companies and AV professionals seeking versatility and reliability.
DSP | |
Input: | 4 channels |
Output: | 4 channels |
PC connection Port: | Front panel features 1 USB communication port; rear panel includes 1 USB port plus 2 RS485 ports (RJ-45 connectors). |
Processor: | 48KHz Sampling frequency, 48-bit Fixed-Point DSP, 24-bit A/D and D/A converter |
Dynamic range: | >110dB |
Frequency Response: | ±0.25dB, 20Hz ---20KHz |
Distortion: | < 0.01%, 20Hz - 20KHz @ +10dBu balanced input |
Signal to noise ratio: | >110dB |
crossover filter: | Independent LPF/HPF per channel; Filter: Butterworth/Bessel/Linkwitz-Riley; Frequency: 20 Hz–20 kHz; Slope: 12/18/24/48 dB/oct. |
EQ: | Bandwidth:0.2 to 36 ct, Frequency:20Hz to 20KHz, Gain: -24dB to +12dB, step:0.2 dB |
Delay: | 0ms to 115ms |
Display: | 2 x 20 LCD |
Store Settings: | 20 user program dynamic storage |
AMPLIFICATION | DSP5004S digital dsp pro audio power amplifier |
Output Power | |
8Ω Stereo Power | 4×500W |
4Ω Stereo Power | 4×800W |
8Ω Bridged Monon Power | 2×1500W |
Frequenty Response | 20Hz-20kHz ±0.5dB |
THD+N：1KHz | 0.10% |
Signal Noise Ration(dB) | 110dB |
Input Impedance | 20KΩ Balanced / 10kΩ Unbalanced |
Output Connectors | Speakon Connectors (NEUTRIK) |
Power Requirement | 100-120V-50-60Hz or 200-240V-50-60Hz |
Dimension | 483×44×325mm |
Net weight | 5.8kg |
